True MFG Co.

True Mfg. TDM-DZ-59-GE/GE-B-W 59-Inch Curved Glass Dual Zone Display Merchandiser

$9,650.40 ~~Sale price$27,146.00you save $17,495.60~~

Key Features:

Dual Zone Display (Dry + Refrigerated): Simultaneously merchandises refrigerated and dry goods in separate, independently controlled zones, making it ideal for bakeries, delis, and specialty food retail environments.
Precise Temperature Control: Refrigerated section maintains a standard cabinet temperature of 33°F to 41°F (0.5°C to 5°C) for bakery and cold deli products; an optional temperature range of 42°F to 65°F (5.5°C to 18.3°C) is available for chocolate and wine applications.
Curved Glass Front and Side Panels: Elegant curved glass design on both the front and ends delivers maximum product visibility and an upscale presentation suited for high-end desserts and pastries.
Self-Contained Hydrocarbon Refrigeration: Factory-balanced, self-contained refrigeration system uses an environmentally responsible hydrocarbon refrigerant with zero ozone depletion potential (ODP) and zero global warming potential (GWP), simplifying installation.
Six Adjustable Wire Cantilever Shelves: Six tiered levels of adjustable wire cantilever shelves, each rated to support up to 150 lbs (69 kg), accommodate a wide variety of product sizes and display configurations. Cabinet holds eight 18"L x 26"D display pans and four 9"L x 26"D display pans (pans not included).
LED Interior Lighting: Safety-shielded LED lighting delivers bright, even illumination throughout the cabinet interior, enhancing product appeal while minimizing energy consumption.
Easy Access and Maintenance Design: Front curved glass swings up for simple interior cleaning access; two rear sliding glass doors allow quick product loading from the back. The pull-out condensing unit slides out for effortless cleaning and service.
Heavy-Duty, Corrosion-Resistant Construction: Features a welded heavy-duty steel frame rail with black powder coat for corrosion protection. The refrigerator evaporator is epoxy coated to further resist corrosion. Exterior is powder coated FDA-approved black; interior is powder coated FDA white over CRS material.
Foamed-In-Place Polyurethane Insulation: The entire cabinet structure is insulated with high-density, foamed-in-place polyurethane, ensuring thermal efficiency and structural integrity.
NSF/ANSI Standard 7 Compliant: Certified to hold open food product in compliance with NSF/ANSI Standard 7, meeting strict food safety requirements for commercial foodservice applications.
Industry Certifications and Made in USA: Certified CE, cULus, and UL EPH classified; proudly manufactured in the USA. Operates on 115V/60Hz/1-phase, 10.0A with a NEMA 5-15P plug.
Companion Unit Compatibility: Designed to bank with True's TDM-R refrigerated display merchandiser for seamless multi-unit installations in high-volume retail settings (note: a 1/2" gap remains between banked units due to side panel design).
Leg Levelers Included: Frame rail is fitted with adjustable leg levelers to ensure stable, level installation on uneven floors.

Fresno

Usually ready in 2-4 days

Sacramento

Usually ready in 2-4 days

True Mfg. TDM-DZ-59-GE/GE-B-W 59-Inch Curved Glass Dual Zone Display Merchandiser

$9,650.40~~$27,146.00~~

Detailed Description

The True Mfg. TDM-DZ-59-GE/GE-B-W is a 59-inch curved glass dual-zone display merchandiser purpose-built for high-volume commercial foodservice, combining a refrigerated zone (33°F-41°F) and a dry ambient zone within a single, elegant cabinet. Its curved glass front and glass end panels deliver panoramic product visibility from multiple angles, making it an outstanding choice for showcasing premium desserts, pastries, and bakery goods in delis, specialty grocery stores, and upscale cafes. The black powder-coated exterior and crisp white interior create a polished, professional aesthetic, while six tiers of adjustable wire cantilever shelves provide versatile, high-capacity merchandising. Self-contained hydrocarbon refrigeration with a pull-out condensing unit simplifies installation and routine maintenance, and the foamed-in-place polyurethane insulation carries zero ozone depletion and zero global warming potential.

Product Details

Dual-Zone Display

Simultaneously showcases dry and refrigerated products in a single 59" cabinet.

Precise Temperature Control

Refrigerated zone holds 33°F to 41°F; optional 42°F to 65°F range for chocolate and wine.

Heavy-Duty Construction

Welded steel frame with powder-coated black exterior and white FDA-approved interior finish.

True TDM-DZ-59-GE/GE-B-W 59-inch curved glass dual-zone bakery display merchandiser with black exterior and white interior, showing tiered shelving

Elegant Curved Glass for Maximum Product Visibility

The TDM-DZ-59-GE/GE-B-W features a sweeping curved glass front and glass end panels that showcase pastries, desserts, and deli items with unmatched clarity. The lift-up front glass and two rear sliding glass doors make restocking and cleaning effortless during peak service hours.

Curved glass front and glass side panels for 360-degree product visibility
Front glass swings up for quick, unobstructed cleaning access
Two rear sliding glass doors for fast back-of-case reloading
LED interior lighting distributes even, safety-shielded illumination throughout the cabinet

Key Specifications

Dimensions59.25" W x 39" D x 49-54" H

Electrical115V / 60Hz / 1-phase / 10.0A, NEMA 5-15P

Shelving6 adjustable wire cantilever shelves, 150 lb capacity each

RefrigerationSelf-contained hydrocarbon, pull-out condensing unit

CertificationsNSF/ANSI 7, CE, cULus, UL EPH Classified, Made in USA

InsulationHigh-density polyurethane, zero ODP and zero GWP

Performance at a Glance

59.25"

Cabinet Width

Adjustable Shelves

33-41°F

Refrigerated Zone Range

Ideal For

Bakeries and patisseries Deli and grocery retail Convenience stores Catering and hospitality Chocolate and wine display High-volume food retail

From the Cresco Resco Team

Why You'll Love It

The True TDM-DZ-59-GE/GE-B-W delivers a rare combination of stunning curved-glass presentation and reliable dual-zone temperature management in a single, self-contained cabinet.

Perfect for operations that need to display both refrigerated pastries and dry bakery items side by side without a second unit.
The pull-out condensing unit and lift-up front glass make daily maintenance faster, keeping case downtime to a minimum.
Banks seamlessly with True's TDM-R refrigerated display merchandiser for an expanded, cohesive display lineup.

Specifications

Model	TDM-DZ-59-GE/GE-B-W
Type	Dual Zone Curved Glass Display Merchandiser (Dry / Refrigerated)
Width	59.25"
Depth	39"
Height	49" - 54"
Weight	770 lbs (350 kg)
Exterior Finish	Black powder-coated (FDA approved), aluminum aesthetic side and front panels
Interior Finish	White powder-coated FDA over CRS material
Front Glass	Curved glass, swings up for easy cleaning access
End Panels	Glass
Rear Access	2 sliding glass doors
Shelves	6 adjustable wire cantilever shelves
Shelf Capacity	150 lbs (69 kg) per shelf
Pan Capacity	8 x (18"L x 26"D) display pans; 4 x (9"L x 26"D) display pans (pans not included)
Refrigeration	Self-contained hydrocarbon refrigeration
Standard Temperature Range	33°F to 41°F (0.5°C to 5°C)
Optional Temperature Range	42°F to 65°F (5.5°C to 18.3°C)
Electrical Requirements	115V / 60Hz / 1-phase, 10.0A
NEMA Configuration	5-15P
Lighting	LED interior lighting (safety shielded)
Insulation	Foamed-in-place high-density polyurethane; zero ODP and zero GWP
Frame	Welded heavy-duty steel frame rail, black powder-coated for corrosion protection
Evaporator	Epoxy coated to prevent corrosion
Condensing Unit	Pull-out design for easy cleaning and maintenance
Leveling	Leg levelers on frame rail
Certifications	CE, cULus, UL EPH Classified, NSF/ANSI Standard 7
Made in USA	Yes
