Mega Top Prep Space for High Volume Lines
Built for fast assembly and organized ingredients, this three section sandwich and salad prep table pairs a large pan opening with a ready to work top.
- 30 pan opening for ingredient layout
- Includes insulated pan cover
- 9-1/2 inch deep, 1/2 inch thick polyethylene cutting board with side rail
Reach In Storage Below the Work Surface
Keep backup product cold and accessible in a 23.0 cu. ft. cabinet with three solid doors and bright interior lighting.
- (3) stainless steel doors with recessed handles
- (3) stainless steel wire shelves
- LED interior lighting with fan control
Reliable Refrigeration System, Easy to Monitor
A self contained, rear mounted refrigeration system uses R290 refrigerant and a digital control and monitor system to help keep temperatures consistent.
- R290 hydrocarbon refrigerant
- Self cleaning condenser equipped (automatic daily brushing)
- 2/5 HP, 115v, 60 Hz, 1 phase, NEMA 5-15P
Built for Daily Service
Stainless steel construction and foamed in place insulation support long life performance in busy prep lines.
- Stainless steel interior and exterior (galvanized steel back and bottom)
- ABS door liner and high density polyurethane insulation
- 4 inch swivel casters with locks on the front set
Why You'll Love It
A high capacity mega top prep table that keeps ingredients cold, organized, and ready for fast assembly.
- Great for sandwich and salad stations that need a 30 pan opening and 23.0 cu. ft. storage.
- Cold Bunker airflow helps maintain safe pan temperatures even during frequent lid openings.
- Self cleaning condenser helps protect performance with daily automatic brushing.
| Model | TST-72SD-30-N |
| Type | Super Deluxe Sandwich/Salad Mega Top Unit |
| Number of Sections | 3 |
| Number of Doors | 3 |
| Door Style | Stainless Steel with Recess Handles |
| Door Liner | ABS |
| Lid Type | Standard (Insulated Pan Cover) |
| Dimensions (W x D x H) | 72-5/8" x 34" x 39-5/8" |
| Capacity | 23.0 cu. ft. |
| Pan Capacity | 30-pan opening |
| Included Pans | 1/6 size, 4" deep condiment pans |
| Compatible Pan Size | 1/6 size, up to 6" deep |
| Interior Construction | Stainless Steel |
| Exterior Construction | Stainless Steel (Galvanized Steel Back & Bottom) |
| Shelving | (3) Stainless Steel Wire Shelves |
| Insulation | High-Density CFC-Free Polyurethane (Foamed-in-Place) |
| Cutting Board | 9-1/2" Deep, 1/2" Thick High-Density Polyethylene with Side Rail |
| Lighting | LED Interior Lighting with Fan Control |
| Temperature Range | 33°F to 39°F |
| Refrigeration System | Self-Contained, Rear Mounted |
| Condenser | Self-Cleaning |
| Refrigerant | R-290 Hydrocarbon |
| Horsepower | 2/5 HP |
| Voltage | 115V/60/1-Ph |
| Amperage | 5.7 Amps |
| Plug Type | NEMA 5-15P |
| Casters | 4" Diameter Swivel Casters with Locks on Front Set |
| Certifications | cETLus, ETL-Sanitation |
| Parts & Labor Warranty | 5 Years |
| Compressor Warranty | 7 Years |
