True MFG Co.

True Manufacturing TBB-4G-S-HC-LD 90 3/8" Glass Door Stainless Steel Back Bar Refrigerator with LED Lighting

$5,790.45 ~~Sale price$19,161.00you save $13,370.55~~

Key Features:

Three-section back bar cooler with 90 3/8" width and 32.8 cu. ft. capacity, capable of holding (152) 6-packs of 12 oz. cans or (4) half-barrel kegs with shelves removed
Three swing-style double-pane low-E insulated glass doors with positive seals, magnetic gaskets, and integrated locks for product visibility and off-hours security
Stainless steel exterior, countertop, and interior floor with a reinforced 1/2" lip designed to support heavy keg loads; aluminum back and galvanized steel interior walls
Six black PVC-coated wire shelves adjustable in 1/2" increments for flexible beverage organization; two right shelves at 20 3/4" W x 19 3/8" D, and four middle/left shelves at 31 3/4" W x 21 1/4" D
Eco-friendly R-290 hydrocarbon refrigerant (ODP of 0, GWP of 3) via capillary tube system maintains temperatures between 33-38 degrees F
LED interior lighting provides bright, even illumination, generates less heat than fluorescent alternatives, and is safety shielded for added protection
Slide-out condensing unit accessible behind the front grille for simplified servicing and cleaning
20-second reverse condensing fan motor technology purges debris from the coil surface at each compressor start-up, improving efficiency and reducing maintenance requirements
Full-body, foamed-in-place high-density polyurethane insulation maximizes temperature retention and adds structural rigidity to the cabinet
Left-side compressor location; operates on 115V/60Hz/1-phase with a 7-ft. cord and NEMA 5-15P plug, drawing just 2.8A at 1/4 HP

Detailed Description

The True TBB-4G-S-HC-LD is a three-section back bar cooler built for high-volume bar operations, offering 32.8 cu. ft. of capacity in a stainless steel cabinet that holds up to 152 six-packs or 4 half-barrel kegs. Its three double-pane, low-E insulated glass doors with magnetic gaskets and locks provide excellent product visibility while maintaining temperatures between 33 and 38 degrees Fahrenheit. The unit runs on eco-friendly R290 hydrocarbon refrigerant with a capillary tube system, and features a slide-out condenser accessible from the front grille for straightforward maintenance. Six adjustable, black PVC-coated wire shelves and energy-efficient LED interior lighting complete a package engineered for both durability and operational efficiency behind the bar.

Product Details

Consistent Cold Temperatures

Maintains a precise 33-38°F range to keep every beverage perfectly chilled.

High-Volume Storage Capacity

Holds 152 six-packs of 12 oz. cans or 4 half-barrel kegs across 32.8 cu. ft.

Eco-Friendly R290 Refrigerant

Capillary tube system uses R290 hydrocarbon refrigerant with zero ozone depletion potential.

True TBB-4G-S-HC-LD stainless steel back bar cooler with three glass swing doors stocked with cans and bottles

Three-Section Glass Door Back Bar Cooler

The True TBB-4G-S-HC-LD is a professional-grade back bar refrigerator engineered for high-traffic bar and restaurant environments. Its 90 3/8" stainless steel profile offers expansive storage while keeping your beverage selection visible and accessible at all times.

Three double-pane thermal glass swing doors with magnetic gaskets and positive seals
Door locks secure beverages during off-hours
LED interior lighting enhances product visibility and generates less heat than fluorescent bulbs
Stainless steel exterior, countertop, and interior floor resist rust and clean up quickly

Key Specifications

Capacity32.8 cu. ft.

Temperature Range33-38°F

RefrigerantR290 Hydrocarbon

Shelves6 PVC-coated, adjustable in 1/2" increments

Electrical115V/60Hz/1ph, 2.8A, 1/4 HP, NEMA 5-15P

Dimensions (W x D x H)90 3/8" x 29 7/8" x 37"

Built for Demanding Bar Environments

152

6-Packs of 12 oz. Cans

Half-Barrel Kegs (shelves removed)

32.8

Cu. Ft. Interior Volume

The stainless steel interior floor features a 1/2"-thick reinforced lip designed to support the full weight of heavy half-barrel kegs during loading and unloading. Full-body foamed-in-place polyurethane insulation maintains cold temperatures while adding structural rigidity to the cabinet.

Slide-out condenser accessed from behind the front grille simplifies routine servicing
20-second reverse condensing fan motor clears debris from the coil surface on each compressor start-up
Door threshold protector guards against scuffs during loading
Black powder-coated steel frame rail provides enhanced structural strength

Ideal For

Full-service bars High-volume restaurants Nightclubs and lounges Hospitality venues Sports bars Hotel bar programs

From the Cresco Resco Team

Why You'll Love It

The True TBB-4G-S-HC-LD delivers the storage capacity, durability, and energy efficiency that busy bar operations demand.

Perfect for bars and restaurants that need to keep a large, visible selection of cans, bottles, and kegs always chilled and ready to serve.
Double-pane glass doors with LED lighting let staff and customers see the full selection without opening the cabinet, improving efficiency and reducing cold-air loss.
R290 hydrocarbon refrigerant and self-cleaning reverse-cycle condenser fan motor keep operating costs low and maintenance simple over the long run.

Specifications

Model	TBB-4G-S-HC-LD
Series	TBB Series
Product Type	Back Bar Cooler
Number of Doors	3
Door Type	Swing
Door Material	Double-Pane Thermal Glass (Low-E Insulated)
Number of Shelves	6
Shelf Material	Black PVC-Coated Wire
Shelf Adjustment Increment	1/2 in.
Capacity	32.8 cu. ft.
Can Capacity	152 six-packs (12 oz. cans)
Keg Capacity (1/2 Barrel)	4 (shelves removed)
Temperature Range	33°F - 38°F
Refrigerant	R-290 (Hydrocarbon)
Compressor Location	Left
Horsepower	1/4 HP
Voltage / Frequency / Phase	115V / 60 Hz / 1 Ph
Amperage	2.8 A
NEMA Configuration	5-15P
Cord Length	7 ft.
Exterior Material	Stainless Steel
Interior Floor Material	Stainless Steel
Interior Wall Material	Galvanized Steel
Interior Back Material	Aluminum
Insulation	Foamed-In-Place Polyurethane
Lighting	LED Interior
Special Features	Door Locks, Magnetic Gaskets, Slide-Out Condenser, 20-Second Reverse Condensing Fan Motor
Base	Frame (Black Powder-Coated Steel)
Width	90 3/8 in.
Depth	29 7/8 in.
Height	37 in.
Weight	585 lbs. (266 kg)
Shelf Dimensions (Right, 2 shelves)	20 3/4 in. W x 19 3/8 in. D
Shelf Dimensions (Middle & Left, 4 shelves)	31 3/4 in. W x 21 1/4 in. D
Warranty	7-Year Parts & Labor; 7-Year Compressor
UPC	400016567212
