JOHN BOOS & CO.

John Boos UBIB-1836-CP7-X 36" Underbar Ice Bin/Cocktail Unit with 7-Circuit Cold Plate

$2,138.00

Key Features:

7-Circuit Cold Plate: Integrated cold plate keeps soda and beverage lines chilled during service, making this unit a true cocktail station hub for high-volume bar operations.
Insulated Ice Bin with Drain: 13-1/2" deep insulated bin (34"W x 15" front-to-back) slows ice melt for extended holding periods, with a built-in drain to manage meltwater efficiently.
2-Piece Sliding Lid: Convenient sliding two-piece lid provides quick, one-handed access to the ice bin while keeping ice covered and protected when not in use.
18/300 Stainless Steel Construction: 18-gauge, 300-series stainless steel body delivers lasting corrosion resistance and durability in demanding commercial bar environments.
Welded 3" Backsplash: Factory-welded backsplash creates a seamless, easy-to-clean barrier against spills and splashes at the back of the unit.
Adjustable Stainless Steel Bullet Feet: Height-adjustable bullet feet provide stable leveling on both tiled and smooth floor surfaces, with stainless steel legs and cross-bracing for rigid structural support.
Slim-Line Underbar Profile: Compact 36"W x 18"D x 32-1/2"H footprint fits standard underbar configurations without sacrificing bin capacity (approx. 148 lbs of ice).
NSF Certified: Meets NSF sanitation standards, ensuring compliance in health-inspected commercial foodservice environments.

John Boos UBIB-1836-CP7-X 36" Underbar Ice Bin/Cocktail Unit with 7-Circuit Cold Plate

$2,138.00

Detailed Description

The John Boos UBIB-1836-CP7-X is a slim-line underbar ice bin and cocktail unit built for high-volume bar operations that demand reliability and efficiency. Its 34W x 15D x 13.5-deep insulated ice bin holds approximately 148 lbs of ice and slows melt rates for extended service periods, while the integrated drain handles meltwater with ease. A seven-circuit cold plate is built directly into the unit to keep soda and syrup lines chilled without additional refrigeration. The entire body is fabricated from 18-gauge, 300-series stainless steel, providing a durable and corrosion-resistant structure ideal for the demanding bar environment. NSF-certified and finished with adjustable bullet feet and stainless steel leg and side bracing, this unit installs cleanly under standard bar counters.

Product Details

7-Circuit Cold Plate

Keeps soda and beverage lines chilled throughout service for consistent pour quality.

Insulated Ice Bin with Drain

13.5" deep insulated bin slows ice melt, and a built-in drain handles meltwater effortlessly.

18/300 Stainless Steel Build

18-gauge 300-series stainless steel construction delivers corrosion resistance built for demanding bar environments.

John Boos UBIB-1836-CP7-X 36-inch stainless steel underbar ice bin and cocktail unit with 2-piece sliding lid, condiment holder, and adjustable bullet feet

Slim-Line Design Built for the Underbar

The John Boos UBIB-1836-CP7-X is a professional slim-line cocktail unit engineered to fit neatly under standard bar counters while delivering serious ice-holding and cold-plate performance. The 2-piece sliding lid allows easy access to the bin without interrupting service flow.

Overall: 36"W x 18"D x 32.5"H
Bin interior: 34"W x 15"D x 13.5"H
Welded 3" backsplash for splash control
2-piece sliding lid for quick access
Stainless steel legs with side bracing for stability

Key Specifications

Cold Plate7-circuit

Ice CapacityApprox. 148 lbs.

Material18-gauge 18/300 stainless steel

CertificationNSF

Bin Size34"W x 15"D x 13.5"H

Warranty1 year against defects

Ideal For

Full-service bars Hotel and resort lounges Restaurant cocktail stations Sports venues and event bars Soda gun setups requiring cold-plate cooling

From the Cresco Resco Team

Why You'll Love It

The John Boos UBIB-1836-CP7-X brings together heavy-duty stainless steel durability and a practical 7-circuit cold plate in one slim, underbar-ready footprint.

Perfect for busy commercial bars that need reliable ice holding and chilled beverage line performance in a compact unit.
The insulated bin holds approximately 148 lbs. of ice while the built-in drain keeps the workspace clean and dry.
NSF certified and built from 18/300 stainless steel with adjustable bullet feet, making it ready for real-world bar conditions right out of the box.

Specifications

Brand	John Boos
Model Number	UBIB-1836-CP7-X
Type	Freestanding Underbar Ice Bin / Cocktail Unit
Overall Dimensions (W x D x H)	36" x 18" x 32-1/2"
Bin Dimensions (W x D x H)	34" W x 15" front-to-back x 13-1/2" deep
Construction Material	18-gauge, 18/300 Stainless Steel
Cold Plate Circuits	7-Circuit
Backsplash Height	3"
Lid Type	2-Piece Sliding Lid
Feet	Adjustable Stainless Steel Bullet Feet
Leg & Bracing Material	Stainless Steel Legs with Side Bracing
Ice Capacity (Approximate)	148 lbs.
Drain	Yes
Weight	191 lbs.
Certifications	NSF
Warranty	1-Year Against Defects in Material & Workmanship
