Bromic Heating BH3130052 Affinity 5-Channel On/Off Controller

$321.00

Key Features:

2-Channel On/Off Control, 12,000W Total Capacity (6kW/Ch): Each channel supports up to 6,000W of electric load or up to 10 gas heaters, delivering powerful and scalable control for both residential and commercial outdoor heating installations.
Broad Heater Compatibility: Works seamlessly with Bromic Platinum and Tungsten Series gas and electric heaters, operating across a wide voltage range of 120V-277V (single or two-phase), making it suitable for diverse commercial electrical configurations.
Wi-Fi (2.4GHz) and Bluetooth Connectivity: Control heaters remotely via the Bromic Smart-Heat App on iOS or Android - manage zones, set schedules, and monitor performance from anywhere on your network or within 30 ft over Bluetooth.
Advanced Scheduling and Zone Management: Supports timer and schedule settings, multi-heater grouping within zones, and multi-site management from a single app, ideal for large venues, restaurants, and hospitality environments.
Voice Control Integration: Compatible with Amazon Alexa and Google Home for hands-free operation, plus admin-level multi-user management for streamlined team access in commercial settings.
Optional BMS and Ethernet Integration: An optional expansion board adds Ethernet connectivity and 0-10V compatibility, enabling integration with home automation or building management systems (BMS) for full smart infrastructure support.
IP54-Rated, Outdoor-Durable Enclosure: Weather-resistant construction rated for outdoor use in temperatures from -4°F to 86°F, with flexible wall or ceiling mounting options for both indoor and outdoor installations.
Safety Certified: Listed to UL 60730-1 and CAN/CSA E60730-1 standards, with a 1-year manufacturer warranty, ensuring compliance and peace of mind for commercial deployments.

Bromic Heating BH3130052 Affinity 5-Channel On/Off Controller

$321.00

Detailed Description

The Bromic Affinity Smart-Heat On/Off Controller (BH3130052) is a 2-channel wireless heating controller engineered for seamless management of Bromic Platinum and Tungsten gas and electric heaters in demanding commercial and residential outdoor environments. Each of its two independent channels supports up to 6,000W at 208-277V, delivering a combined 12,000W capacity and the ability to control up to 10 gas heaters per channel. Built-in Wi-Fi (2.4GHz) and Bluetooth connectivity pair with the Bromic Smart-Heat App on iOS and Android, enabling zone grouping, timer scheduling, multi-site management, and voice control via Amazon Alexa and Google Home. An IP54-rated enclosure rated for operation between -4°F and 86°F ensures long-term durability in outdoor settings, while an optional expansion board unlocks Ethernet and 0-10V integration for building management systems. UL 60730-1 and CAN/CSA E60730-1 certified, with flexible wall or ceiling mounting for both indoor and outdoor installations.

Product Details

12,000W Dual-Channel Power

Each channel handles up to 6,000W at 208-277V, or up to 10 gas heaters per channel.

Smart App Control

Manage zones, set timers, and control heaters remotely via the Bromic Smart-Heat App on iOS or Android.

Outdoor-Rated Durability

IP54 weather-resistant enclosure rated for -4°F to 86°F operation, built for demanding outdoor environments.

Key Specifications

Total Power12,000W (6kW/Ch)

Channels2 Channel

Voltage Range208V - 277V

ConnectivityWi-Fi (2.4GHz), Bluetooth, Ethernet

Weather RatingIP54 Outdoor Rated

CertificationsUL 60730-1, CAN/CSA E60730-1

InstallationWall or ceiling mount; indoor & outdoor

Warranty1 Year Manufacturer

At a Glance

12,000W

Total Power Capacity

Independent Channels

IP54

Weather Resistance

Smart Features Overview

The Bromic Affinity Smart-Heat On/Off Controller brings full-featured wireless management to your outdoor heating setup. Key capabilities include:

Wi-Fi and Bluetooth remote control via the Bromic Smart-Heat App
Voice control integration with Amazon Alexa and Google Home
Timer and schedule settings for automated heating routines
Multi-heater zone grouping and management from a single app
Optional Ethernet and 0-10V BMS integration via expansion board
Compatible with Bromic Platinum and Tungsten gas and electric heaters

Ideal For

Residential patios Commercial outdoor spaces Multi-heater installations Smart home integration Building management systems

From the Cresco Resco Team

Why You'll Love It

The Bromic Affinity Smart-Heat On/Off Controller (2-Channel) is the intelligent hub for effortless, powerful outdoor heating management.

Perfect for homeowners and commercial operators who need reliable, app-based control over multiple heaters across two independent zones.
Delivers 12,000W of total capacity with IP54 outdoor durability, voice assistant compatibility, and optional BMS expansion for professional installations.
Pairs seamlessly with Bromic Platinum and Tungsten series heaters for a complete, connected outdoor heating ecosystem.

Specifications

Model	BH3130052
Product Type	Smart Heat On/Off Controller
Channels	2 Channel
Total Power Capacity	12,000W (6kW per channel)
Gas Heater Capacity	Up to 10 gas heaters per channel
Voltage Range	208-277V (Single or Two-Phase)
Connectivity	Wi-Fi (2.4GHz), Bluetooth (up to 30 ft range); optional Ethernet via Expansion Board
Heater Compatibility	Bromic Platinum and Tungsten Series (Gas and Electric)
App Support	Bromic Smart-Heat App (iOS and Android)
Voice Control	Amazon Alexa, Google Home
Installation	Wall or ceiling mounted; indoor and outdoor rated
Weather Rating	IP54
Operating Temperature	-4°F to 86°F (up to 50°C)
Finish / Color	Gray
Item Dimensions (L x W x H)	11.4" x 8" x 4.4"
Item Weight	3.1 lbs
Certifications	UL 60730-1, CAN/CSA E60730-1
Warranty	1 Year Manufacturer
