American Range

American Range AR-48G 48 Inch Space Saver Gas Range with 48 Inch Griddle and (2) Ovens

$9,681.00 ~~Precio rebajado$20,380.00ahorra $10,699.00~~

Key Features:

48 inch space saver commercial gas range with a full-width 48 inch griddle top.
Heavy-duty griddle: 1 inch thick steel plate with 3 inch wide grease collector; one 20,000 BTU/hr burner every 12 inches with manual controls and pilots for each burner.
Two 20 inch space saver ovens with two racks per oven; accommodates 18 inch x 26 inch sheet pans front to back.
Oven performance and safety: 27,000 BTU/hr steel oven burner, 250°F to 500°F thermostat range, porcelain enamel interior, spring-assisted counterweight doors, and 100% safety gas shutoff.
High output for demanding kitchens: 134,000 total BTU (40.0 kW).
Durable, easy-clean exterior: stainless steel front and sides with 6 inch chrome-plated adjustable legs; selectable stub back, high riser, or high riser with shelf at no charge.
Compliance and build: cETLus and ETL-Sanitation listed; designed and built in the USA.
Warranty: 2-year limited parts and labor warranty.

Detailed Description

The American Range AR-48G is a 48 inch commercial gas restaurant range built for high-output griddling and baking in a compact footprint. A full-width 1 inch thick griddle plate delivers even heat for breakfast, sandwiches, and high-volume production, while two space saver ovens add baking and finishing capacity. With 134,000 BTU total input and durable stainless steel construction, it is designed for demanding service lines. The unit includes 6 inch chrome-plated legs and offers backguard options to fit your ventilation and workflow needs.

Product Details

High-Output Cooking Power

Up to 134,000 BTU total for fast recovery in busy kitchens.

Griddle Plus Double Ovens

48 inch griddle top with two space saver ovens for multi-task service.

Built for Commercial Use

Stainless steel front and sides for durability and easier wipe-downs.

American Range AR-48G 48 inch restaurant gas range with griddle top and double oven doors

48 Inch Restaurant Range for Service Speed

A compact, high-capacity layout that combines a full-width griddle surface with two ovens to keep tickets moving during peak hours.

48 inch restaurant range configuration with griddle top
Two space saver ovens with two racks per oven
Backriser options available (high back with shelf, high back, or 6 inch stub back)

Note: Product image may show optional accessories.

Key Specs at a Glance

Total Output

134,000 BTU

Griddle Plate

1 inch thick plate

Overall Size

48 in W x 32.25 in D x 56 in H

Oven Temperature Range

250 to 500 degrees F

Designed for Daily Volume

32,000 BTU/hr open burners (with anti-clog, lift-off burner heads on applicable configurations)
20,000 BTU/hr griddle on 48 inch griddle configurations
Two-year limited warranty (parts and labor)

From the Cresco Resco Team

Why You'll Love It

A space-smart 48 inch restaurant range that pairs an all-day griddle with double ovens to support fast, consistent production.

Great for diners, cafes, and line cooking where griddling and baking happen side by side.
Heavy-duty build with stainless steel front and sides.
Strong total BTU output for responsive cooking during rushes.

Specifications

Manufacturer	American Range
Model	AR-48G
Equipment Type	48 in commercial gas restaurant range with griddle and (2) space saver ovens
Fuel Type	Gas
Total Heat Output	134,000 BTU
Total Connected Load	40.0 kW
Electrical	120V, 1 phase
Overall Dimensions (W x D x H)	48 in x 32.25 in x 56 in
Weight	660 lb
Griddle	(1) 48 in griddle, 1 in thick plate
Ovens	(2) space saver ovens; includes (2) racks per oven
Space Saver Oven Interior Dimensions (each)	20 in W x 26.5 in D x 13.5 in H
Oven Thermostat Range	250°F to 500°F (121°C to 260°C)
Oven Burner Rating	27,000 BTU/hr (each space saver oven burner)
Construction	Stainless steel front and sides
Backguard Options	6 in stainless stub back, high riser, or high riser with shelf (no charge options)
Legs	6 in chrome plated legs
Certifications	cETLus; ETL-Sanitation
Country of Origin	Made in USA
Warranty	2 year limited parts and labor
