Imperial IR-6-G24-C-XB 60 in Gas Restaurant Range with 6 Burners, 24 in Griddle, Convection Oven and Open Cabinet
Regular price
$15,046.00
Sale price$33,436.00you save $18,390.00
Detailed Description
The Imperial IR-6-G24-C-XB is a 60 inch Pro Series gas restaurant range built to consolidate high-output open-burner cooking, griddling, and baking into one heavy-duty platform. It pairs six open burners with a 24 inch griddle section and a convection oven powered by a 1/2 HP blower motor for faster, more even baking. A stainless steel exterior and cast iron grates support demanding line use, while the open cabinet base adds accessible storage beneath the cooktop. This model is listed NSF and includes a removable grease can and crumb tray for easier cleanup.
Product Details
High-Output Cooking Power
262,000 BTU total for demanding service.
Convection Baking Performance
Built-in convection oven with 1/2 HP blower motor.
Built for Busy Kitchens
Stainless steel front and sides with cast iron grates.
Complete 60 Inch Workstation
A single range that combines open burners, a griddle surface, a convection oven, and an open cabinet base.
- 60 inch wide gas Pro Series range
- Six open burners with pilot lights and low simmer feature
- Convection oven plus open cabinet with bottom shelf
24 Inch Griddle for High-Volume Output
Keep breakfast, burgers, and saute production moving with an integrated 24 inch griddle section.
- 24 inch griddle with 3 inch grease trough
- Removable grease can and crumb tray for easier cleanup
- Cast iron grates for dependable pan support
Oven Capacity Where You Need It
Finish and bake with a convection oven, while the open cabinet base keeps essentials close at hand.
- Convection oven with porcelain interior
- Three chrome racks included
- 6 inch legs with adjustable feet
Key Specifications
Type
Gas restaurant range
Width
60 in
Top Configuration
(6) open burners, (1) 24 in griddle
Total Heat
262,000 BTU
Base
(1) convection oven, (1) open cabinet with bottom shelf
Certifications
NSF, CE, CSA Flame, CSA Star
From the Cresco Resco Team
Why You'll Love It
The IR-6-G24-C-XB delivers a versatile, heavy-duty cooking line in one 60 inch footprint.
- Great for kitchens that need burners, griddle space, and baking capacity on one range.
- Integrated convection oven plus open cabinet storage for efficient workflow.
- Easy-to-service design details like removable grease can and crumb tray.
Specifications
| Manufacturer | Imperial |
| Model / MPN | IR-6-G24-C-XB |
| Series | Pro Series |
| Power Source | Gas (natural gas or LP; specify) |
| Overall Width | 60 in |
| Overall Depth | 31.5 in |
| Overall Height | 56.5 in |
| Top Configuration | (6) open burners plus (1) 24 in griddle |
| Griddle Plate Thickness | 0.75 in (3/4 in) |
| Griddle Grease Management | 3 in grease trough; removable grease can and crumb tray |
| Oven Configuration | (1) convection oven plus (1) open cabinet with bottom shelf |
| Convection Oven Motor | 1/2 HP blower motor |
| Convection Oven Electrical (standard) | 120V / 1-ph / 6.0A |
| Included Oven Racks | (3) chrome racks |
| Construction / Finish | Stainless steel front, sides, and backguard (with shelf) |
| Burner Features | Pilot lights; low simmer feature; cast iron grates |
| Legs | 6 in legs with adjustable feet |
| Certifications | NSF; CE; CSA Flame; CSA Star |
| Total BTU | 262,000 BTU or 292,000 BTU (source discrepancy) |
| Shipping Weight | 1065 lb |
