American Range AF-35/50 Floor Model Gas Tube Fryer, 50 lb Oil Capacity

$1,496.00 ~~Sale price$3,195.00you save $1,699.00~~

Key Features:

Floor-model, tube-type gas fryer with (1) vat and 35 to 50 lb oil capacity for medium to high volume frying
120,000 BTU/hr heat input with three burner tubes and alloy diffuser for improved heat transfer
Durable stainless construction with heavy-gauge stainless steel fry tank
Millivolt control system with safety shutoff, does not require an electrical connection
Thermostatic temperature control from 200°F to 400°F for consistent frying results
Large cool zone helps collect crumbs and reduce burning and flavor transfer
Includes 2 baskets and an easy-drain valve for simpler filtering and cleanup

Denver

Usually ready in 2-4 days

Las Vegas

Usually ready in 2-4 days

American Range AF-35/50 Floor Model Gas Tube Fryer, 50 lb Oil Capacity

$1,496.00~~$3,195.00~~

Detailed Description

The American Range AF-35/50 is a floor model, tube-type gas fryer built for consistent recovery and dependable day-to-day frying. Its stainless steel construction and TIG-welded fry tank are designed for durability and easier cleanup in busy kitchens. A millivolt pilot system with safety shutoff and thermostatic controls help maintain stable operation without requiring electrical power. The deep tank with a cool zone helps keep sediment out of the frying area to support oil life and product quality.

Product Details

200 to 400°F Control Range

Thermostatic control for consistent, repeatable frying results.

120,000 BTU Tube-Type Heating

High-output performance to support quicker heat recovery.

Cool Zone and Drain Valve

Cool zone helps collect crumbs, plus a drain simplifies oil removal.

American Range AF-35/50 commercial floor gas fryer with two hanging baskets

Floor Fryer Built for Daily Service

The American Range AF-35/50 is a tube-type commercial gas fryer designed for dependable throughput with straightforward controls and durable stainless steel construction.

Single-vat design with 35 to 50 lb oil capacity range
Millivolt control system with safety shutoff
Includes two baskets for efficient batch frying

Why Choose This Model

35 to 50 lb

Oil Capacity Range

120,000

BTU Output

200 to 400°F

Temperature Range

Ideal For

Fast-casual kitchens Concessions and snack bars Restaurant fry stations Breaded foods and fried sides

From the Cresco Resco Team

Why You'll Love It

A reliable, high-output floor fryer that prioritizes temperature control, recovery, and easier day-to-day cleanup.

Great for medium to high volume service where consistency matters.
Tube-type heat and a cool zone help support cleaner oil and steadier results.
Simple controls and included baskets make it easy to put to work on the line.

Specifications

Manufacturer	American Range
Model	AF-35/50
Configuration	Floor model, tube-type gas fryer
Number of vats	1
Oil capacity	50 lb (listed as 35 to 50 lb range)
Total input	120,000 BTU/hr
Number of burners	3
Temperature range	200 to 400 F
Controls / ignition	Millivolt control / millivolt pilot system (no electrical connection required)
Material	Stainless steel front and sides; 304 stainless steel TIG-welded fry tank (stainless construction)
Cool zone	Large cool zone below tubes
Drain valve	Full-port drain valve (size varies by source: 1 in vs 1-1/4 in)
Basket quantity	2
Legs	6 in adjustable legs (optional casters referenced)
Overall dimensions (W x D x H)	15.5 in x 30.5 in x 45.75 in
Frying area	14 in x 14 in
Gas type	Natural gas (NG)
Gas connection	1/2 in NPT rear gas inlet
Certifications	cETLus, ETL-Sanitation (listed)
Country of origin	Made in USA (listed)
Approx. shipping weight	163 lb (150 lb also listed)
Warranty	5-year tank warranty (other coverage varies by source)
